The PIERCE 9,000 lbs. 11 Drum Industrial Electric Winch is shown with a lever against a black background.

PIERCE 9,000 lbs. 11 Drum Industrial Electric Winch features a cylindrical drum, control lever, and 9000 marking, delivering powerful 9,000 lb pulling capacity for industrial use.

The PIERCE 9,000 lbs. 11 Drum Industrial Electric Winch motor, shown front-facing with visible wiring and connectors, is engineered for dependable pulling power in worm gear winch applications.

PIERCE 9,000 lbs. 11 Drum Industrial Electric Winch with handle and power cord, offering strong pulling force, isolated on white background.

The PIERCE 9,000 lbs. 11 Drum Industrial Electric Winch features black and metallic elements and a handle, delivering 9,000 lbs of pulling force.

The PIERCE 9,000 lbs. 11 Drum Industrial Electric Winch features a black metal body with bolts and cables for powerful pulling, isolated on a white background.

The PIERCE 9,000 lbs. 11 Drum Industrial Electric Winch features a black motor with attached wires and metal casing, shown from the side against a white background.

1 11

9,000 lbs. 11" Drum Industrial Electric Winch

PSW654-11K

$1,338.00

Save 20% by bundling together!

Controllers

2 Function Wireless Remote Control System
PS002 $ 258.00
$206.40
PIERCE 2 function Momentary Hard-Wired Control ...
CP271 $ 48.00
$38.40

Installation Mounts

Universal Angle Mounts
PT037 $ 42.00
$33.60
Receiver Hitch Mount
PBM1RH $ 165.00
$132.00
Standard Winch Mount 654 Series
PBM1 $ 103.00
$82.40

Winch Cable

3/8" Winch Cable - 125 ft / Safety Swivel Hook
PS0364SS $ 155.00
$124.00
3/8" Winch Cable - 125 ft / Self Locking Hook
PS0364SLH $ 186.00
$148.80

Quantity

In stock

Alternatives: 9,000 lbs. 11" Drum Industrial Electric Winch

9,000 lbs. 8" Drum Industrial Electric Winch 9,000 lbs. 11" Drum Industrial Electric Winch 12,500 lbs. 8" Drum Industrial Electric Winch 12,500 lbs. 11" Drum Industrial Electric Winch

WARNING

This Winch is not intended or designed to transport people. Do not use winch to hold a load during transportation

9,000 lbs. 11" Drum Industrial Electric Winch

Description

The PIERCE worm gear winch provides a reliable and consistent pulling force, supporting loads up to 9,000 lbs. Its strong build is used in various industries globally. With easy access to spare parts and the ability to be used on-site, this winch is a smart investment. Plus, it comes with a limited lifetime warranty.

Included

1 x [PSW654-11K] - 9,000 lbs. 11" Drum Industrial Electric Winch↗

1 x [P040] - PIERCE Toggle Switch Remote - 20ft Cord - 4 Prong Vulcanized Plug↗

1 x Instructions

Specifications

Specification	Details
BRAKE TYPE	Worm Gear Brake
CLUTCH TYPE	Dog
CONSTRUCTION	Cast Metal
DRUM ROTATION	Counter-Clockwise (Underwound)
DRUM SIZE	3 ½ in. x 11 in.
GEAR RATIO	470:1
GEAR TYPE	Worm Gear
MAX AMPS	400
MAX CAPACITY (LBS.)	9000
MAX LINE SPEED	14 fpm
MOTOR (HP)	1.5
OPERATING VOLTAGE	12 Volts DC
POWER SOURCE	Electric, DC
RECOMMENDED BATTERY	650 CCA
RECOMMENDED WIRE	2 gauge
RECOMMENDED WIRE ROPE	⅜ in. x 125 ft.

FAQs

Can I use a fuse to protect my winch and vehicle?

Yes, a fuse or circuit breaker is highly recommended to protect your winch and vehicle from electrical damage. A 400-amp circuit breaker is ideal, as it handles amperage spikes during winching and resets easily, unlike costly 400-amp fuses. Alternatively, a cut-off switch is a budget-friendly option to disconnect power during a short circuit, though it won’t prevent spikes. Always use properly rated devices for safety.

What precautions should I take when pulling heavy loads?

Place a heavy blanket, jacket, or winch dampener over the wire rope during heavy pulls. If the rope snaps, the cloth can help absorb energy and reduce dangerous backlash. Ensure the item is thick, secure, and placed midway along the taut rope. This simple step protects you and others nearby during tasks like vehicle recovery or heavy towing.

How can I provide a safe anchor point while winching?

Use a D-ring or bow shackle rated for your winch’s pulling capacity with a tree trunk protector or similar anchor strap. Select a sturdy anchor like a healthy tree or vehicle tow point. Wrap the protector around the anchor, attach the shackle, and connect the winch cable. Ensure all gear is rated for the load and check connections before winching. This prevents equipment failure or injury during tasks like vehicle recovery.

How can I double my winch pulling capacity?

You can double your winch’s pulling capacity by using a snatch block, which is a pulley system that redirects the winch cable. Here’s how it works: Attach the snatch block to the load or a secure anchor point, then run the winch cable through the pulley and back to a fixed point, like the tow hook on your vehicle. This setup effectively halves the load on the winch by distributing it across two cable lines, allowing it to pull twice as much weight.

How much pulling power do I need from my winch?

Choose a winch with a pulling capacity at least 1.5 times your vehicle’s gross weight to handle obstacles like mud, snow, sand, water, or steep hills. For example, a 6,000-pound vehicle needs a winch rated for at least 9,000 pounds. This ensures enough power for safe recovery in tough conditions without overloading the winch.

How do I secure a load with my winch?

Use ratchet straps or tie-downs to secure a load safely. Winches are not suitable for tying down loads, as constant movement or vibration can damage their gears. Choose high-quality ratchet straps rated for the load’s weight and attach them to secure anchor points on your vehicle or trailer. Check straps for wear and ensure they’re tight to prevent shifting during transport.

What maintenance is required on my winch?

Regular maintenance extends your winch’s life. Lubricate all grease points, tighten bolts, and inspect electrical connections, especially at the battery, for corrosion or loose fittings. Check the wire rope for wear, flat spots, or broken strands; replace if damaged. Refer to your winch manual for specific checks. Routine care prevents breakdowns and ensures safe operation during tasks like vehicle recovery.

How do I re-spool the wire rope onto my winch?

Always wear leather gloves when re-spooling wire rope to protect your hands. Never use bare hands, as the rope can cause cuts or burns. Keep a slight load on the rope to spool it evenly. Guide the rope with one gloved hand while using the remote control in the other to operate the winch. This ensures safe, tight spooling for effective winching.

What should I do about my vehicles wheels while winching?

Place wheel chocks or sturdy blocks under your vehicle’s wheels before winching. This prevents the vehicle from rolling forward or backward, keeping it stable and safe during the pull. Use solid materials like wood, rubber chocks, or stones, and position them snugly against the tires. This is especially important on slopes or loose terrain during tasks like vehicle recovery.

Can I increase the line speed of my worm gear winch?

Yes, but it reduces pulling power by about 50%. For electric winches, swapping gears can boost line speed up to 50%. For hydraulic winches, replacing the motor with one of different displacement can increase speed. Consult your winch manual or a professional for proper modifications to ensure safe operation and avoid damage during tasks like vehicle recovery.

Resources

PSW654 Series Winch Manual

PS002 - PS528CN - Wiring Diagram

Spec Sheet

P040 - Wiring Diagram

Wiring Diagram

PS528C-NV2 - Compact Solenoid Assembly Wiring

Wiring Diagram

Videos

Warranty

Limited Lifetime Warranty

Mechanical Parts guaranteed free of Defects.

Mechanical parts are guaranteed to be free of manufacturer defects.
Parts will be replaced at the manufacturer's discretion.

Electrical Components have a 2 Year Warranty

Warranty ensures that electrical components are free from defects.
The Warranty period is taken from the date the goods leave our factory, although we will accept a later date if the Distributor can confirm date of purchase.

Conditions

Does not include normal wear and tear, misuse, water damage or other forms of abuse.
Electrical components must have proper wiring verified and be protected by appropriate fuses, breakers, and power disconnects to qualify for any warranty coverage.
This warranty only covers the original products sold by PIERCE. Labor, down time, loss of work and other expenses are not included in this warranty.
You must contact us first to receive a return merchandise authorization number and instructions to return and receive warranty.
All return shipping logistics and costs are non-refundable and the responsibility of the buyer.
Call us to explain the problem, making sure you have both the model number and the serial number on hand. Often, we can resolve the matter over the phone.

Replacement Parts

Replacement 12 Volt Winch Motor | Electric Worm Gear Winches

Standard equipment for PIERCE winches. Runs at 1.5 hp. The motor is composed of high-temperature components, fore and aft ball bearings, and a 3/4" shaft cut for a woodruff key. The two parallel posts are fields while the post in the rear is the a...

SKU: PS534HSW $150.00

12V Round Compact Solenoid Assembly

This product replaces the can, mechanical-style solenoids with a compact-style. Product Includes: One compact solenoid Two field wires (one positive wire, one armature wire with boots and eyes) Plug wires with spade connections Ground wire Femal...

SKU: PS528C-NV2 $154.00

PIERCE Toggle Switch Remote - 20ft Cord - 4 Prong Vulcanized Plug

The PIERCE Toggle Switch Remote is an essential component for PIERCE Industrial Winches. It offers two functions, with a four-prong vulcanized plug and a 20-foot cord. This remote is specifically designed to work with the PIERCE Industrial Series ...

SKU: P040 $48.00

Receiver Hitch Mount

This receiver hitch mounts our PS654 Series winch to your receiver. Creates a removable and portable mount. Fits 2" receiver hitch. Constructed for 1/4" plated steel.

SKU: PBM1RH $165.00

Universal Angle Mounts

Universal angle mounts for flush mounting PS654 winches. Pre-cut and drilled. 2" x 2" x 1/4" angle iron. Fits 8" and 11" drum.

SKU: PT037 $42.00

Standard Winch Mount 654 Series

The standard winch mount for 654 series is a heavy duty mount with 1/4" plated steel, and pre-drilled holes. The product aids in mounting the winch to flat surfaces.

SKU: PBM1 $103.00

2 Function Wireless Remote Control System

The PIERCE wireless remote control system, with 2 functions and an operating distance of 150 ft (45 m), is perfect for managing any 12/24V solenoid-operated equipment. The system features a Mini transmitter with an IP 65 rating and a receiver with...

SKU: PS002 $258.00
