Contracting and Construction
Hydraulic Power Units
Construction sites run on hydraulics — dump beds, auxiliary lifts, cranes, and tilt functions all need reliable power. The power up / gravity down unit runs standard dump applications. The dual action pump adds powered lowering for controlled placement of heavy loads. The 4-way pump handles multi-circuit setups where a single truck is running several hydraulic functions, which is common on service body builds and contractor trucks with multiple auxiliary attachments.
Bucher Power Up, Gravity Down Hydraulic Power Unit
Standard power up / gravity down unit for dump bed operations. The reliable, no-frills power unit for contractor trucks that load and dump material throughout the day.
$530.00
PM-319-6P
Bucher Dual Action (Power Up / Power Down) Hydraulic Pump
Dual action pump with powered control in both directions. On contractor trucks, the controlled lowering is valuable when placing heavy loads precisely — setting a pallet of block off the back of a bed, or lowering a tilt deck with equipment on it.
$691.00
PM-3554-0131
Bucher 4 Way Pump
Four-way pump for multi-circuit hydraulic setups where a single truck runs several functions — common on service body builds and contractor trucks with crane, outrigger, and dump circuits.
$1,028.00
PM-3530
Winches
Winches on a construction site pull equipment, materials, and structural components into position. The industrial hydraulic winch is built for continuous-duty pulling on truck-mounted crane setups and service bodies. The 12,500 lb and 11,000 lb electric winches handle heavy pulls where hydraulic lines aren’t already plumbed — pulling pipe, setting forms, dragging equipment onto trailers, or tensioning cables. The 110V option runs off standard power for shop and yard work.
PIERCE 110V Electric Winch – 11,000 lb, 8" Drum (Planetary Drive)
110V electric winch that runs off standard power for shop, yard, and job site work. Handles heavy pulling, loading, and positioning tasks where a generator or site power is available but hydraulic lines are not.
$2,039.00
PS654-8EMK
12,500 lbs. 8" Drum Industrial Electric Winch
Heavy-duty electric winch for pulling pipe, setting forms, dragging equipment onto trailers, and tensioning cables on the job site. Handles heavy pulls where hydraulic lines aren’t already plumbed.
$1,529.00
PSW654-8MK
Controls & Remotes
On a construction site, the operator is rarely in the cab when they need to control the truck’s hydraulic functions. They’re at the tailgate watching a load dump, on the ground guiding a crane, or standing clear while a bed tilts. Wireless remotes from 2 to 6 functions scale with the complexity of the truck’s setup. The 6-function wireless handles multi-circuit trucks running dump, tilt, and auxiliary lines simultaneously. The toggle switch remote is built for the abuse of a job site where mud, concrete dust, and rough handling are the norm.
2 Function Wireless Remote Control System
Two-function wireless remote for operating dump beds and tilt functions from the tailgate or ground level. Lets the operator watch where the load is going instead of being stuck in the cab.
$275.00
PS002
4 Function Wireless Remote Control System
Four-function wireless for multi-circuit contractor trucks running dump, tilt, crane, and auxiliary functions. Controls the full range of hydraulic operations from a single transmitter.
$412.00
PS004
PIERCE Toggle Switch Remote - 20ft Cord - 4 Prong Vulcanized Plug
Hardwired toggle switch built for the abuse of a construction site — mud, concrete dust, and rough handling. Provides reliable dump and tilt control without depending on wireless signal.
$48.00
P040
Dump Bed Kits
Contractors live and die by how fast they can move material on and off a job site. Dump bed kits turn crew trucks and flatbeds into self-unloading haulers — gravel for a foundation, fill dirt for grading, concrete debris from a demo. The flat bed kits come in light, medium, and heavy duty to match the truck and the typical load, from a residential remodel crew to a commercial excavation outfit. The factory bed kit keeps the OEM pickup bed for contractors who need enclosed sides to contain loose materials and tools.
Frequently Asked Questions
Can't find the answer you're looking for? Contact our team and we'll get back to you.
Can I use a fuse to protect my winch and vehicle?
Yes, a fuse or circuit breaker is highly recommended to protect your winch and vehicle from electrical damage. A 400-amp circuit breaker is ideal, as it handles amperage spikes during winching and resets easily, unlike costly 400-amp fuses. Alternatively, a cut-off switch is a budget-friendly option to disconnect power during a short circuit, though it won’t prevent spikes. Always use properly rated devices for safety.
What precautions should I take when pulling heavy loads?
Place a heavy blanket, jacket, or winch dampener over the wire rope during heavy pulls. If the rope snaps, the cloth can help absorb energy and reduce dangerous backlash. Ensure the item is thick, secure, and placed midway along the taut rope. This simple step protects you and others nearby during tasks like vehicle recovery or heavy towing.
How can I provide a safe anchor point while winching?
Use a D-ring or bow shackle rated for your winch’s pulling capacity with a tree trunk protector or similar anchor strap. Select a sturdy anchor like a healthy tree or vehicle tow point. Wrap the protector around the anchor, attach the shackle, and connect the winch cable. Ensure all gear is rated for the load and check connections before winching. This prevents equipment failure or injury during tasks like vehicle recovery.
How can I double my winch pulling capacity?
You can double your winch’s pulling capacity by using a snatch block, which is a pulley system that redirects the winch cable. Here’s how it works: Attach the snatch block to the load or a secure anchor point, then run the winch cable through the pulley and back to a fixed point, like the tow hook on your vehicle. This setup effectively halves the load on the winch by distributing it across two cable lines, allowing it to pull twice as much weight.
How much pulling power do I need from my winch?
Choose a winch with a pulling capacity at least 1.5 times your vehicle’s gross weight to handle obstacles like mud, snow, sand, water, or steep hills. For example, a 6,000-pound vehicle needs a winch rated for at least 9,000 pounds. This ensures enough power for safe recovery in tough conditions without overloading the winch.
How do I secure a load with my winch?
Use ratchet straps or tie-downs to secure a load safely. Winches are not suitable for tying down loads, as constant movement or vibration can damage their gears. Choose high-quality ratchet straps rated for the load’s weight and attach them to secure anchor points on your vehicle or trailer. Check straps for wear and ensure they’re tight to prevent shifting during transport.
What maintenance is required on my winch?
Regular maintenance extends your winch’s life. Lubricate all grease points, tighten bolts, and inspect electrical connections, especially at the battery, for corrosion or loose fittings. Check the wire rope for wear, flat spots, or broken strands; replace if damaged. Refer to your winch manual for specific checks. Routine care prevents breakdowns and ensures safe operation during tasks like vehicle recovery.
How do I re-spool the wire rope onto my winch?
Always wear leather gloves when re-spooling wire rope to protect your hands. Never use bare hands, as the rope can cause cuts or burns. Keep a slight load on the rope to spool it evenly. Guide the rope with one gloved hand while using the remote control in the other to operate the winch. This ensures safe, tight spooling for effective winching.
What should I do about my vehicles wheels while winching?
Place wheel chocks or sturdy blocks under your vehicle’s wheels before winching. This prevents the vehicle from rolling forward or backward, keeping it stable and safe during the pull. Use solid materials like wood, rubber chocks, or stones, and position them snugly against the tires. This is especially important on slopes or loose terrain during tasks like vehicle recovery.
Can I increase the line speed of my worm gear winch?
Yes, but it reduces pulling power by about 50%. For electric winches, swapping gears can boost line speed up to 50%. For hydraulic winches, replacing the motor with one of different displacement can increase speed. Consult your winch manual or a professional for proper modifications to ensure safe operation and avoid damage during tasks like vehicle recovery.
