Car Hauling
Controls & Remotes
Car hauling is a one-person job most of the time, and that one person needs to be at the back of the trailer watching the vehicle load — not in the cab operating controls they can’t see. Wireless remotes let the operator tilt the deck, run the winch, and control bed functions while guiding the vehicle onto the carrier. The 4-function wireless adds control over auxiliary functions like wheel stops or secondary winch lines. The toggle switch and pendant remotes serve operators who prefer the reliability of a wired connection, especially in high-volume lots where interference from other equipment is a factor.
2 Function Wireless Remote Control System
Two-function wireless remote for operating tilt deck and winch from anywhere around the trailer. The car hauling operator can stand at the ramp watching ground clearance and guiding the vehicle while controlling the bed and winch wirelessly.
$275.00
PS002
Universal Momentary Pendant Control - 2 Button
Simple two-button pendant for basic winch operation during vehicle loading. A reliable, no-frills control for operators who run the winch while standing at the trailer ramp guiding vehicles onto the carrier.
$17.00
CP077
2 Function Wireless Control System for Dump Trailer
Purpose-built wireless system for trailer-mounted operations. Car haulers running tilt-deck or ramp trailers can operate the tilt and winch functions wirelessly while positioned at the back of the trailer watching the vehicle load.
$308.00
PS002TS
4 Function Wireless Remote Control System
Four-function wireless remote for car hauling rigs with multiple hydraulic circuits — tilt deck, winch, wheel stops, and auxiliary functions all controlled from a single handheld transmitter.
$412.00
PS004
PIERCE Toggle Switch Remote - 20ft Cord - 4 Prong Vulcanized Plug
Hardwired toggle switch remote for reliable dump and tilt control. Popular with car haulers who prefer a wired connection that works consistently in busy lots where wireless interference from nearby equipment can be a factor.
$48.00
P040
Hydraulic Power Units
Hydraulic power units run the tilt decks, ramps, and bed functions on car hauling trailers and rollback carriers. The power up / gravity down unit is the workhorse for standard tilt-deck trailers where the bed tilts under its own weight. The 2-way power up / power down unit gives operators precise control over bed angle during loading — critical when pulling low-clearance vehicles onto a carrier where the approach angle needs to be managed carefully to avoid scraping bumpers or splitters.
Bucher Power Up, Gravity Down Hydraulic Power Unit
The standard power unit for tilt-deck car hauling trailers. Powers the bed up under load and gravity handles the tilt-down — simple, reliable operation for the repetitive load/unload cycles of daily car hauling.
$530.00
PM-319-6P
Bucher Pump 2 Way (Power Up / Power Down) 1.5 gal. Poly Reservoir
Compact two-way hydraulic power unit for car hauling trailers and carriers. Powers tilt-deck and ramp hydraulics with a reliable, self-contained unit that mounts cleanly on the trailer frame.
$631.00
PM-3551-0667
Bucher Pump 2 Way (Power Up / Power Down) 2.5 gal. Poly Reservoir
Two-way power up / power down unit for car hauling trailers where controlled bed descent is critical. Low-clearance vehicles — lowered cars, sports cars with front splitters — need a precisely controlled approach angle during loading to avoid scraping.
$641.00
PM-3551
Recovery Winches
Recovery winches pull non-running vehicles onto carriers and trailers. Most passenger vehicles fall well within the 9,000 to 12,000 lb winch range, but the real demand is duty cycle — a car hauler loading and unloading multiple vehicles per day puts far more hours on a winch than occasional recovery use. Replacement motors for the PS6000 and PS15000/PS20000 series keep working winches in service, which matters for haulers who can’t afford downtime waiting on a full winch replacement.
12,000 lb Recovery Winch
The higher-capacity winch for pulling full-size trucks, SUVs, and heavier vehicles onto carriers. Handles the heavier end of the passenger vehicle range and provides extra margin for non-running vehicles on wet or gravel surfaces.
$821.00
PS12000
9,000 lb Recovery Winch
Handles pulling most passenger vehicles — sedans, coupes, and compact SUVs — onto carriers and trailers. The 9,000 lb rating provides solid margin over typical passenger vehicle weights for non-running pulls.
$625.00
PS9000
6,000 lb Electric Planetary Winch Motor | Style 1
Replacement motor for the PS6000 series. Keeps lighter-duty winch setups operational on car hauling trailers and smaller carriers without a full winch replacement.
$107.00
PSM6-3
Frequently Asked Questions
Can't find the answer you're looking for? Contact our team and we'll get back to you.
Can I use a fuse to protect my winch and vehicle?
Yes, a fuse or circuit breaker is highly recommended to protect your winch and vehicle from electrical damage. A 400-amp circuit breaker is ideal, as it handles amperage spikes during winching and resets easily, unlike costly 400-amp fuses. Alternatively, a cut-off switch is a budget-friendly option to disconnect power during a short circuit, though it won’t prevent spikes. Always use properly rated devices for safety.
What precautions should I take when pulling heavy loads?
Place a heavy blanket, jacket, or winch dampener over the wire rope during heavy pulls. If the rope snaps, the cloth can help absorb energy and reduce dangerous backlash. Ensure the item is thick, secure, and placed midway along the taut rope. This simple step protects you and others nearby during tasks like vehicle recovery or heavy towing.
How can I provide a safe anchor point while winching?
Use a D-ring or bow shackle rated for your winch’s pulling capacity with a tree trunk protector or similar anchor strap. Select a sturdy anchor like a healthy tree or vehicle tow point. Wrap the protector around the anchor, attach the shackle, and connect the winch cable. Ensure all gear is rated for the load and check connections before winching. This prevents equipment failure or injury during tasks like vehicle recovery.
How can I double my winch pulling capacity?
You can double your winch’s pulling capacity by using a snatch block, which is a pulley system that redirects the winch cable. Here’s how it works: Attach the snatch block to the load or a secure anchor point, then run the winch cable through the pulley and back to a fixed point, like the tow hook on your vehicle. This setup effectively halves the load on the winch by distributing it across two cable lines, allowing it to pull twice as much weight.
How much pulling power do I need from my winch?
Choose a winch with a pulling capacity at least 1.5 times your vehicle’s gross weight to handle obstacles like mud, snow, sand, water, or steep hills. For example, a 6,000-pound vehicle needs a winch rated for at least 9,000 pounds. This ensures enough power for safe recovery in tough conditions without overloading the winch.
How do I secure a load with my winch?
Use ratchet straps or tie-downs to secure a load safely. Winches are not suitable for tying down loads, as constant movement or vibration can damage their gears. Choose high-quality ratchet straps rated for the load’s weight and attach them to secure anchor points on your vehicle or trailer. Check straps for wear and ensure they’re tight to prevent shifting during transport.
What maintenance is required on my winch?
Regular maintenance extends your winch’s life. Lubricate all grease points, tighten bolts, and inspect electrical connections, especially at the battery, for corrosion or loose fittings. Check the wire rope for wear, flat spots, or broken strands; replace if damaged. Refer to your winch manual for specific checks. Routine care prevents breakdowns and ensures safe operation during tasks like vehicle recovery.
How do I re-spool the wire rope onto my winch?
Always wear leather gloves when re-spooling wire rope to protect your hands. Never use bare hands, as the rope can cause cuts or burns. Keep a slight load on the rope to spool it evenly. Guide the rope with one gloved hand while using the remote control in the other to operate the winch. This ensures safe, tight spooling for effective winching.
What should I do about my vehicles wheels while winching?
Place wheel chocks or sturdy blocks under your vehicle’s wheels before winching. This prevents the vehicle from rolling forward or backward, keeping it stable and safe during the pull. Use solid materials like wood, rubber chocks, or stones, and position them snugly against the tires. This is especially important on slopes or loose terrain during tasks like vehicle recovery.
Can I increase the line speed of my worm gear winch?
Yes, but it reduces pulling power by about 50%. For electric winches, swapping gears can boost line speed up to 50%. For hydraulic winches, replacing the motor with one of different displacement can increase speed. Consult your winch manual or a professional for proper modifications to ensure safe operation and avoid damage during tasks like vehicle recovery.
What maintenance is recommended for these Hydraulic Power Units?
Every 2-3 months, check electrical connections for corrosion and tightness from unit to battery. Check the fluid condition and level. Inspect the breather/filler cap as well for missing foam or dirt. Every year we recommend changing out your hydraulic fluid.
What fluid is recommended in this Hydraulic Power Unit?
We recommend ATF (Automatic Transmission Fluid) for almost every case. In very low temperatures (Below -20°F / -30°C) the ATF will thicken. In this cold weather, ensure the reservoir is filled to the recommended level and consider preheating the fluid or using a reservoir heater.
Can I use this hydraulic power unit to run my hydraulic winch?
Short answer: No. Long answer: Yes, but it will be a slow, sad, and disappointing experience. While the operating pressure is often correct, the 1.5 gpm (gallons per minute) vs the 15 gpm of a clutch or PTO pump is going to be a tenth of the performance you'd want at best.
