Storage
Controls & Remotes
Controls and remotes in storage operations let a single worker operate winches, liftgates, and dump functions while watching the load — critical when pulling items in or out of tight storage units where the operator needs to guide the load and can’t be at the control panel simultaneously. The range from simple 2-button pendants to 4-function wireless covers everything from a single winch at a loading dock to a yard truck running dump and auxiliary functions.
4 Function Wireless Control System | PS Series
Four-function wireless for yard trucks running dump, liftgate, and auxiliary functions from a single transmitter.
$412.00
PS004
2 Function Wireless Control System | PS Series
Wireless remote for operating winches, liftgates, and dump functions while watching the load in tight storage units.
$275.00
PS002
PIERCE Toggle Switch Remote - 20ft Cord - 4 Prong Vulcanized Plug
Hardwired toggle switch for dump and liftgate control on facility trucks. Simple and durable for repetitive daily operations.
$53.00
P040
Bucher Power-Up / Gravity-Down HPU | 6 qt Poly
Power up / gravity down unit powering the dump beds and hydraulic functions that the remotes and pendants in this category operate.
$530.00
PM-319-6P
Universal Momentary Pendant Control - 2 Button
Two-button pendant for single-function winch or liftgate control at loading docks and container yards.
$17.00
CP077
Electric Winches
Electric winches in storage operations pull heavy loads into and out of storage units, containers, and warehouse bays. The 110V winch runs off standard facility power for fixed installations at loading docks and container yards — pulling heavy equipment, loaded pallets, and oversized items that can’t be moved by hand or forklift. The 12,500 lb portable electric winch handles mobile pulling tasks around the yard.
12,500 lb 12V Worm Gear Winch | 8 in Drum
Portable 12,500 lb electric winch for mobile pulling tasks around the storage yard.
$1,529.00
PSW654-8MK
11,000 lb 110V Worm Gear Winch | 8 in Drum
110V winch running off standard facility power for fixed installations at loading docks and container yards.
$2,039.00
PS654-8EMK
Dump Bed Kits
Storage facilities — self-storage yards, warehouses, and distribution centers — need to move bulk materials for property maintenance, construction, and site management. A dump bed kit handles gravel for drainage and parking areas, soil for landscaping, and debris from cleanouts or demolition. The factory bed kit serves facility maintenance trucks that also carry tools and supplies, while the flat bed kit handles higher-volume material hauling for larger storage operations.
Frequently Asked Questions
Can't find the answer you're looking for? Contact our team and we'll get back to you.
Can I use a fuse to protect my winch and vehicle?
Yes, a fuse or circuit breaker is highly recommended to protect your winch and vehicle from electrical damage. A 400-amp circuit breaker is ideal, as it handles amperage spikes during winching and resets easily, unlike costly 400-amp fuses. Alternatively, a cut-off switch is a budget-friendly option to disconnect power during a short circuit, though it won’t prevent spikes. Always use properly rated devices for safety.
What precautions should I take when pulling heavy loads?
Place a heavy blanket, jacket, or winch dampener over the wire rope during heavy pulls. If the rope snaps, the cloth can help absorb energy and reduce dangerous backlash. Ensure the item is thick, secure, and placed midway along the taut rope. This simple step protects you and others nearby during tasks like vehicle recovery or heavy towing.
How can I provide a safe anchor point while winching?
Use a D-ring or bow shackle rated for your winch’s pulling capacity with a tree trunk protector or similar anchor strap. Select a sturdy anchor like a healthy tree or vehicle tow point. Wrap the protector around the anchor, attach the shackle, and connect the winch cable. Ensure all gear is rated for the load and check connections before winching. This prevents equipment failure or injury during tasks like vehicle recovery.
How can I double my winch pulling capacity?
You can double your winch’s pulling capacity by using a snatch block, which is a pulley system that redirects the winch cable. Here’s how it works: Attach the snatch block to the load or a secure anchor point, then run the winch cable through the pulley and back to a fixed point, like the tow hook on your vehicle. This setup effectively halves the load on the winch by distributing it across two cable lines, allowing it to pull twice as much weight.
How much pulling power do I need from my winch?
Choose a winch with a pulling capacity at least 1.5 times your vehicle’s gross weight to handle obstacles like mud, snow, sand, water, or steep hills. For example, a 6,000-pound vehicle needs a winch rated for at least 9,000 pounds. This ensures enough power for safe recovery in tough conditions without overloading the winch.
How do I secure a load with my winch?
Use ratchet straps or tie-downs to secure a load safely. Winches are not suitable for tying down loads, as constant movement or vibration can damage their gears. Choose high-quality ratchet straps rated for the load’s weight and attach them to secure anchor points on your vehicle or trailer. Check straps for wear and ensure they’re tight to prevent shifting during transport.
What maintenance is required on my winch?
Regular maintenance extends your winch’s life. Lubricate all grease points, tighten bolts, and inspect electrical connections, especially at the battery, for corrosion or loose fittings. Check the wire rope for wear, flat spots, or broken strands; replace if damaged. Refer to your winch manual for specific checks. Routine care prevents breakdowns and ensures safe operation during tasks like vehicle recovery.
How do I re-spool the wire rope onto my winch?
Always wear leather gloves when re-spooling wire rope to protect your hands. Never use bare hands, as the rope can cause cuts or burns. Keep a slight load on the rope to spool it evenly. Guide the rope with one gloved hand while using the remote control in the other to operate the winch. This ensures safe, tight spooling for effective winching.
What should I do about my vehicles wheels while winching?
Place wheel chocks or sturdy blocks under your vehicle’s wheels before winching. This prevents the vehicle from rolling forward or backward, keeping it stable and safe during the pull. Use solid materials like wood, rubber chocks, or stones, and position them snugly against the tires. This is especially important on slopes or loose terrain during tasks like vehicle recovery.
Can I increase the line speed of my worm gear winch?
Yes, but it reduces pulling power by about 50%. For electric winches, swapping gears can boost line speed up to 50%. For hydraulic winches, replacing the motor with one of different displacement can increase speed. Consult your winch manual or a professional for proper modifications to ensure safe operation and avoid damage during tasks like vehicle recovery.
Videos
Check out how to install the PIERCE 2T Dump Bed Kit with the official PIERCE overview on YouTube.
