Off Roading
Controls & Remotes
During a recovery, the driver is rarely in the vehicle — they’re outside choosing anchor points, routing cable, and watching the pull. Wireless and pendant remotes let the operator control the winch while standing in a safe position away from the cable line, which is a real safety consideration when a cable is under thousands of pounds of tension. The toggle switch remote offers a weather-resistant hardwired option that doesn’t rely on batteries or signal pairing in remote locations.
2 Function Wireless Control System | PS Series
Wireless remote for controlling the winch from a safe standoff distance during recovery. Lets the operator work from the anchor point side of the pull, away from the cable snap zone.
$275.00
PS002
PIERCE Toggle Switch Remote - 20ft Cord - 4 Prong Vulcanized Plug
Weather-resistant hardwired remote that doesn’t rely on batteries or signal pairing in remote locations. A popular choice for off-roaders who want reliable winch control in the backcountry.
$53.00
P040
Universal Momentary Pendant Control - 2 Button
Two-button pendant for straightforward winch-in and winch-out control. A simple, reliable controller for recovery situations where the operator is standing outside the vehicle managing the cable.
$17.00
CP077
Recovery Winches
Self-recovery is the primary use case — pulling a vehicle out when it’s buried in mud, hung up on rocks, or stuck on a trail with no room to maneuver. The 9,000 lb winch covers most Jeeps, side-by-sides, and mid-size rigs, while the 12,000 lb handles full-size trucks and heavily built off-road vehicles. Replacement motors for the PS6000 and PS15000/PS20000 series are critical for off-roaders who put high hours on their winches in demanding conditions — mud, water crossings, and sustained high-load pulls wear motors faster than occasional road-side recovery.
PS6000 Replacement Motor | Style 1 Slotted Shaft
Replacement motor for the PS6000 series. Keeps lighter-duty winch setups operational on Jeeps, side-by-sides, and mid-size off-road rigs.
$138.00
PSM6-3
9,000 lb Electric Recovery Winch | 12V Planetary
The standard self-recovery winch for most Jeeps, side-by-sides, and mid-size off-road rigs. Handles pulling a buried vehicle out of mud, off rocks, and through terrain where there’s no room to maneuver.
$688.00
PS9000
12,000 lb Electric Recovery Winch | 12V Planetary
Higher-capacity recovery winch for full-size trucks and heavily built off-road vehicles. Provides the extra pulling power needed when a loaded, full-size rig is buried deep.
$821.00
PS12000
Frequently Asked Questions
Can't find the answer you're looking for? Contact our team and we'll get back to you.
Can I use a fuse to protect my winch and vehicle?
Yes, a fuse or circuit breaker is highly recommended to protect your winch and vehicle from electrical damage. A 400-amp circuit breaker is ideal, as it handles amperage spikes during winching and resets easily, unlike costly 400-amp fuses. Alternatively, a cut-off switch is a budget-friendly option to disconnect power during a short circuit, though it won’t prevent spikes. Always use properly rated devices for safety.
What precautions should I take when pulling heavy loads?
Place a heavy blanket, jacket, or winch dampener over the wire rope during heavy pulls. If the rope snaps, the cloth can help absorb energy and reduce dangerous backlash. Ensure the item is thick, secure, and placed midway along the taut rope. This simple step protects you and others nearby during tasks like vehicle recovery or heavy towing.
How can I provide a safe anchor point while winching?
Use a D-ring or bow shackle rated for your winch’s pulling capacity with a tree trunk protector or similar anchor strap. Select a sturdy anchor like a healthy tree or vehicle tow point. Wrap the protector around the anchor, attach the shackle, and connect the winch cable. Ensure all gear is rated for the load and check connections before winching. This prevents equipment failure or injury during tasks like vehicle recovery.
How can I double my winch pulling capacity?
You can double your winch’s pulling capacity by using a snatch block, which is a pulley system that redirects the winch cable. Here’s how it works: Attach the snatch block to the load or a secure anchor point, then run the winch cable through the pulley and back to a fixed point, like the tow hook on your vehicle. This setup effectively halves the load on the winch by distributing it across two cable lines, allowing it to pull twice as much weight.
How much pulling power do I need from my winch?
Choose a winch with a pulling capacity at least 1.5 times your vehicle’s gross weight to handle obstacles like mud, snow, sand, water, or steep hills. For example, a 6,000-pound vehicle needs a winch rated for at least 9,000 pounds. This ensures enough power for safe recovery in tough conditions without overloading the winch.
How do I secure a load with my winch?
Use ratchet straps or tie-downs to secure a load safely. Winches are not suitable for tying down loads, as constant movement or vibration can damage their gears. Choose high-quality ratchet straps rated for the load’s weight and attach them to secure anchor points on your vehicle or trailer. Check straps for wear and ensure they’re tight to prevent shifting during transport.
What maintenance is required on my winch?
Regular maintenance extends your winch’s life. Lubricate all grease points, tighten bolts, and inspect electrical connections, especially at the battery, for corrosion or loose fittings. Check the wire rope for wear, flat spots, or broken strands; replace if damaged. Refer to your winch manual for specific checks. Routine care prevents breakdowns and ensures safe operation during tasks like vehicle recovery.
How do I re-spool the wire rope onto my winch?
Always wear leather gloves when re-spooling wire rope to protect your hands. Never use bare hands, as the rope can cause cuts or burns. Keep a slight load on the rope to spool it evenly. Guide the rope with one gloved hand while using the remote control in the other to operate the winch. This ensures safe, tight spooling for effective winching.
What should I do about my vehicles wheels while winching?
Place wheel chocks or sturdy blocks under your vehicle’s wheels before winching. This prevents the vehicle from rolling forward or backward, keeping it stable and safe during the pull. Use solid materials like wood, rubber chocks, or stones, and position them snugly against the tires. This is especially important on slopes or loose terrain during tasks like vehicle recovery.
