Land Owner
Hay & Property Equipment
Rural landowners with acreage manage hay, pasture, and fencing even if ranching isn’t their primary income. The bale spear and 3-point spike kit handle purchasing and placing round bales for supplemental feeding or ground cover. The bale unroller spreads hay for erosion control, wildlife food plots, or seasonal livestock. The t-post puller makes fence maintenance a one-person job — pulling and resetting posts for property boundaries, garden enclosures, or temporary livestock containment without bending posts or breaking them off at the ground.
Truck Bed Gooseneck Hay Bale Mover
Bale spear for purchasing and placing round bales — supplemental feeding, ground cover, erosion control, or seasonal livestock. Turns the property tractor into a bale handler.
$2,158.00
ABS1K
3-Point Hay Bale Unroller
Rolls out hay for erosion control, wildlife food plots, or seasonal livestock feeding directly from the tractor. Covers ground efficiently for landowners managing larger acreage.
AHBR1
3 Point Tractor Bale Spike
Three-point hitch bale spike for handling round bales with any three-point equipped tractor. A practical attachment for landowners who buy hay for feeding or ground cover but don’t have a front-loader setup.
$386.00
ABS3PTLDK
Hauling & Controls
A dump-equipped pickup is one of the most versatile tools on a rural property. It hauls gravel for driveway maintenance, brush and limbs from storm cleanup, topsoil for landscaping, and fence supplies to the back of the property — then dumps the load where it’s needed without shoveling. The wireless remote lets the landowner operate the dump bed from the tailgate, which matters when you’re placing a load precisely and working alone, as most property owners are.
Factory Bed Dump Kit
Converts the property pickup into a dump truck for driveway gravel, storm cleanup brush, topsoil, and fence supplies. Dumps the load where it’s needed without shoveling — the most versatile tool on a rural property.
From $1,746.00
DK2UKPD
2 Function Wireless Remote Control System
Wireless remote for operating the dump bed from the tailgate. Lets the landowner place a load precisely while working alone, which is how most property owners operate day to day.
$275.00
PS002
Recovery Winches
On rural property, things get stuck — ATVs in creek crossings, tractors in muddy fields, trailers on soft ground after a rain. A 9,000 to 12,000 lb recovery winch mounted on the ranch truck handles self-recovery and pulling out equipment without calling for a tow. It also serves utility purposes like dragging fallen trees off roads, pulling stumps, and moving heavy objects that can’t be lifted.
9,000 lb Recovery Winch
Handles self-recovery and equipment extraction on rural property — ATVs stuck in creek crossings, tractors in muddy fields, trailers on soft ground after a rain. Also useful for dragging fallen trees off roads and moving heavy objects.
$625.00
PS9000
12,000 lb Recovery Winch
Higher-capacity recovery winch for pulling full-size trucks, tractors, and heavier equipment out of trouble on rural property. Also handles pulling stumps, dragging logs, and moving heavy objects that can’t be lifted.
$821.00
PS12000
Frequently Asked Questions
Can't find the answer you're looking for? Contact our team and we'll get back to you.
Does the PIERCE Bale Unroller have greased bolts and or grease fitting at all moving points?
Yes. Grease-zerks are found at all moving points.
Does the PIERCE Bale Unroller easily hookup to the quick tractor connects that are popular?
We are looking at utilizing the quick connect option on future revisions of this piece of equipment.
Will the Bale Unroller hook up to both Cat 1 / Cat 2?
Yes
What size bales can the PIERCE Bale Unroller pick up?
The unroller will pick up 5 and 6 foot bales, and will also pick up 4 ft. bales using the extensions.
Will the PIERCE Bale Unroller roll the whole bale out without waste?
The solid “core” will be left (most farmers/ranchers will find a way to feed this as well).
How often should I grease my PIERCE Bale Unroller and what type of grease should I use?
We recommend multipurpose grease (RED). Grease your PIERCE unroller before seasonal use, inspect it every three months, and grease as needed.
How do I hook up the hydraulic connections?
Plug the male into the ½” female breakaway coupler.
Where are PIERCE bale spikes made?
Our shop is located in Henrietta, Texas, United States, where we fabricate, weld, assemble, and service our bale spikes.
How long does the Hydraulic Bale Spear take to lift a bale typically?
With normal pressure and a standard bale you are looking at 15 to 20 seconds.
How long can I expect my PIERCE Hydraulic Bale Spear to last?
With proper maintenance, a 20-year life can reasonably be expected. We routinely see PIERCE bale spikes manufactured in the early 90s still working on ranches locally.
What is the difference between the Gooseneck Bale Spear (ABS1K) and the Bolt-in Bale Spear (ABS2K)?
The ABS1K hay spear installs directly over a gooseneck ball; in comparison, the ABS2K bolts into the truck bed so you can haul trailers while the spear is mounted. Both units come equipped with removable bale spears.
What is the weight limit of Pierce Hydarulic Hay Bale Spears?
PIERCE bale spears have a lifting capacity of 2,500 lbs. NOTE: Picking up bales wider than the rear opening of your truck bed may result in truck damage. Also, Lifting anything other than hay bales will void the warranty and most likely damage your system.
Can I use a fuse to protect my winch and vehicle?
Yes, a fuse or circuit breaker is highly recommended to protect your winch and vehicle from electrical damage. A 400-amp circuit breaker is ideal, as it handles amperage spikes during winching and resets easily, unlike costly 400-amp fuses. Alternatively, a cut-off switch is a budget-friendly option to disconnect power during a short circuit, though it won’t prevent spikes. Always use properly rated devices for safety.
What precautions should I take when pulling heavy loads?
Place a heavy blanket, jacket, or winch dampener over the wire rope during heavy pulls. If the rope snaps, the cloth can help absorb energy and reduce dangerous backlash. Ensure the item is thick, secure, and placed midway along the taut rope. This simple step protects you and others nearby during tasks like vehicle recovery or heavy towing.
How can I provide a safe anchor point while winching?
Use a D-ring or bow shackle rated for your winch’s pulling capacity with a tree trunk protector or similar anchor strap. Select a sturdy anchor like a healthy tree or vehicle tow point. Wrap the protector around the anchor, attach the shackle, and connect the winch cable. Ensure all gear is rated for the load and check connections before winching. This prevents equipment failure or injury during tasks like vehicle recovery.
How can I double my winch pulling capacity?
You can double your winch’s pulling capacity by using a snatch block, which is a pulley system that redirects the winch cable. Here’s how it works: Attach the snatch block to the load or a secure anchor point, then run the winch cable through the pulley and back to a fixed point, like the tow hook on your vehicle. This setup effectively halves the load on the winch by distributing it across two cable lines, allowing it to pull twice as much weight.
How much pulling power do I need from my winch?
Choose a winch with a pulling capacity at least 1.5 times your vehicle’s gross weight to handle obstacles like mud, snow, sand, water, or steep hills. For example, a 6,000-pound vehicle needs a winch rated for at least 9,000 pounds. This ensures enough power for safe recovery in tough conditions without overloading the winch.
How do I secure a load with my winch?
Use ratchet straps or tie-downs to secure a load safely. Winches are not suitable for tying down loads, as constant movement or vibration can damage their gears. Choose high-quality ratchet straps rated for the load’s weight and attach them to secure anchor points on your vehicle or trailer. Check straps for wear and ensure they’re tight to prevent shifting during transport.
What maintenance is required on my winch?
Regular maintenance extends your winch’s life. Lubricate all grease points, tighten bolts, and inspect electrical connections, especially at the battery, for corrosion or loose fittings. Check the wire rope for wear, flat spots, or broken strands; replace if damaged. Refer to your winch manual for specific checks. Routine care prevents breakdowns and ensures safe operation during tasks like vehicle recovery.
How do I re-spool the wire rope onto my winch?
Always wear leather gloves when re-spooling wire rope to protect your hands. Never use bare hands, as the rope can cause cuts or burns. Keep a slight load on the rope to spool it evenly. Guide the rope with one gloved hand while using the remote control in the other to operate the winch. This ensures safe, tight spooling for effective winching.
What should I do about my vehicles wheels while winching?
Place wheel chocks or sturdy blocks under your vehicle’s wheels before winching. This prevents the vehicle from rolling forward or backward, keeping it stable and safe during the pull. Use solid materials like wood, rubber chocks, or stones, and position them snugly against the tires. This is especially important on slopes or loose terrain during tasks like vehicle recovery.
Can I increase the line speed of my worm gear winch?
Yes, but it reduces pulling power by about 50%. For electric winches, swapping gears can boost line speed up to 50%. For hydraulic winches, replacing the motor with one of different displacement can increase speed. Consult your winch manual or a professional for proper modifications to ensure safe operation and avoid damage during tasks like vehicle recovery.
