Name: 2 Function Standard Wireless Actuator Control System | 92 Series | FET Air Receiver
Price: 1008.0 USD
Rating: 5 (1 reviews)

2 Function Standard Wireless Actuator Control System | 92 Series | FET Air Receiver

$1,008.00

1/2

2 Function Standard Wireless Actuator Control System | 92 Series | FET Air Receiver

92150

$1,008.00

In Stock

Simple and reliable. This 2-function Lodar wireless air actuator system includes pneumatic actuators for controlling one valve (two directions). Equipped with a Standard transmitter and sealed receiver for dependable operation.

2 functions = 1 valve of wireless control
Includes pneumatic actuator
Standard Series transmitter (IP54) with AAA x 2 batteries
Receiver sealed to IP67
Requires 90–120 PSI air supply and 12V DC power

Applications: Compact hydraulic systems, auxiliary functions, and light-duty equipment.

Lodar 5 Year Pro-rated Warranty

Warranty is pro-rated and guarantees that product will be free of defect and faults from the manufacturer. See Lodar terms and conditions for more details.

Transmitter

Standard

Functions

Actuator

Air

Operating Voltage

12/24 Volts DC

Transmitter IP Rating

IP 54

Receiver IP Rating

IP 67

Operating Distance

150 ft. (45 m.)

Master Output

Max Amps

Series

9000 Series

Transmitter Batteries

AAA x 2

Special Features

Receiver with Air I/O + Air Actuators

Frequency

433 MHz

Type

Full System

Wiring Included

8 ft. power / 5 ft. air input / 3½ ft. air outputs

Warranty

Lodar 5 Year Pro-rated Warranty

Lodar Replacement Air ValveSKU: AC9918

$228.00

Lodar Replacement Air ActuatorSKU: AC9920

$132.00

2 Function Lodar Replacement Standard Transmitter | 9000 SeriesSKU: 92102TX-8

$247.00

Pairing the 92 Series Lodar Remote & Transmitter

92150 - 2 Function Air System with Standard Transmitter Spec Sheet 92-93 Series - Instructions Standard Transmitter Coding Instructions

5 Year Pro-Rated Warranty

For the first 2 years Warranty is unlimited.

During that period, your Distributor (in the USA, our Service Department) will repair or replace free of charge, at their discretion, any product that is proved to be faulty.
The Warranty period is taken from the date the goods leave our factory, although we will accept a later date if the Distributor can confirm date of purchase.

For the following 3 years Warranty is pro-rated.

During that period, your Distributor will replace with a new product at a discounted price.
These prices are set by each Distributor.
The Warranty period is taken from the date the goods leave our factory, although we will accept a later date if the Distributor can confirm date of purchase.

Conditions

We must receive back either an individual Transmitter or both Transmitter and Receiver, at your cost.
We will not accept individual Receivers. Always send both transmitter and receiver unless otherwise requested.
Discounted products will carry a further 2-year unlimited warranty. After 5 years Lodar cannot be repaired and will be scrapped.
Lodar 8000 Series are now totally out of warranty and are not covered.
Call us to explain the problem, making sure you have both the model number and the serial number on hand. More often than not, we can resolve the matter over the phone.
