2 Function 110V Mini Wireless Control System | 96 Series | Relay Receiver | No Master Output
2 Function 110V Mini Wireless Control System | 96 Series | Relay Receiver | No Master Output
Description
The 2 Function 110V Wireless Mini Transmitter System is designed for professional use, with an IP 67 rating for both transmitter and receiver. It has a wide operating distance of 150 ft. and can handle up to 10 amps, making it suitable for a full range of applications. The compact design and easy installation make it a convenient choice for any certified electrician.
Specifications
| Specification | Details |
|---|---|
| CHANNEL | Wide Band, Fixed |
| FREQUENCY | 418 MHz |
| FUNCTIONS | 2 |
| MASTER OUTPUT | No |
| MAX AMPS | 10 |
| OPERATING DISTANCE | 150 ft. (45 m.) |
| OPERATING TEMPERATURE RANGE | 13ºF - 104ºF (-10ºC to 40ªC) |
| OPERATING VOLTAGE | 110 Volts AC |
| RECEIVER IP RATING | IP 67 |
| SERIES | 9000 Series |
| SWITCH TYPE | Silicone Rubber Keypad with Carbon Pill |
| TRANSMITTER | Mini |
| TRANSMITTER BATTERIES | AAA x 2 |
| TRANSMITTER IP RATING | IP 67 |
| TYPE | Full System |
| WIRING INCLUDED | None |
