Lodar LTD 2 Function IP Wireless Actuator Control System (92 Series) with exposed circuit board, coiled black cable, and remote; FET Air Receiver included, no actuators. For use in Lodar wireless air actuator systems.

2 Function IP Wireless Actuator Control System | 92 Series | FET Air Receiver | No Actuators

$1,018.00
Skip to product information
Lodar LTD 2 Function IP Wireless Actuator Control System (92 Series) with exposed circuit board, coiled black cable, and remote; FET Air Receiver included, no actuators. For use in Lodar wireless air actuator systems.
1/2
  • Lodar LTD 2 Function IP Wireless Actuator Control System (92 Series) with exposed circuit board, coiled black cable, and remote; FET Air Receiver included, no actuators. For use in Lodar wireless air actuator systems.
  • Pairing the 92 Series Lodar Remote & Transmitter
  • Lodar LTD 2 Function IP Wireless Actuator Control System (92 Series) with exposed circuit board, coiled black cable, and remote; FET Air Receiver included, no actuators. For use in Lodar wireless air actuator systems.
  • Pairing the 92 Series Lodar Remote & Transmitter
2 Function IP Wireless Actuator Control System | 92 Series | FET Air Receiver | No Actuators

2 Function IP Wireless Actuator Control System | 92 Series | FET Air Receiver | No Actuators

92270-8
$1,018.00
Out of Stock

This 2-function Lodar 92 Series system provides wireless control of a single valve (two directions) using your own pneumatic actuator. Built with an Industrial transmitter and sealed receiver, it is designed for tough, outdoor environments.

  • 2 functions = 1 valve of wireless control
  • Actuator not included
  • Industrial handheld transmitter (IP65)
  • Receiver sealed to IP65
  • Requires onboard air supply (90–120 PSI) and 12V DC power

Applications: Single-cylinder or auxiliary valve control in recovery, agriculture, and utility trucks where operators supply their own pneumatic actuator.
Lodar 5 Year Pro-rated Warranty icon

Lodar 5 Year Pro-rated Warranty

Warranty is pro-rated and guarantees that product will be free of defect and faults from the manufacturer. See Lodar terms and conditions for more details.

What's Included
Specifications
Transmitter
Industrial Pro
Functions
2
Operating Voltage
12/24 Volts DC
Transmitter IP Rating
IP 65
Receiver IP Rating
IP 65
Operating Distance
150 ft. (45 m.)
Master Output
No
Max Amps
15
Series
9000 Series
Transmitter Batteries
AAA x 4
Special Features
Receiver with Air I/O
Channel
Wide Band, Fixed
Frequency
418 MHz
Type
Full System - No Actuators
Wiring Included
8 ft. power / 5 ft. air input / 3½ ft. air outputs
Warranty
Lodar 5 Year Pro-rated Warranty
Replacement Parts (5)
2 Function Lodar Replacement IP Transmitter | 9000 Series
2 Function Lodar Replacement IP Transmitter | 9000 SeriesSKU: 92202TX-8
$387.00
2 Function Lodar Replacement FET Air Receiver | 92 Series | No Master Output
2 Function Lodar Replacement FET Air Receiver | 92 Series | No Master OutputSKU: 9270RX-8
$632.00
Lodar Replacement Air Valve
Lodar Replacement Air ValveSKU: AC9918
$228.00
Lodar Replacement Air Actuator
Lodar Replacement Air ActuatorSKU: AC9920
$132.00
20 Function Lodar Replacement IP Transmitter | 9000 Series
20 Function Lodar Replacement IP Transmitter | 9000 SeriesSKU: 92220TX-8
$575.00
Videos (1)
Pairing the 92 Series Lodar Remote & Transmitter video

Pairing the 92 Series Lodar Remote & Transmitter

Warranty
5 Year Pro-Rated Warranty
For the first 2 years Warranty is unlimited.
  • During that period, your Distributor (in the USA, our Service Department) will repair or replace free of charge, at their discretion, any product that is proved to be faulty.
  • The Warranty period is taken from the date the goods leave our factory, although we will accept a later date if the Distributor can confirm date of purchase.
For the following 3 years Warranty is pro-rated.
  • During that period, your Distributor will replace with a new product at a discounted price.
  • These prices are set by each Distributor.
  • The Warranty period is taken from the date the goods leave our factory, although we will accept a later date if the Distributor can confirm date of purchase.
Conditions
  • We must receive back either an individual Transmitter or both Transmitter and Receiver, at your cost.
  • We will not accept individual Receivers. Always send both transmitter and receiver unless otherwise requested.
  • Discounted products will carry a further 2-year unlimited warranty. After 5 years Lodar cannot be repaired and will be scrapped.
  • Lodar 8000 Series are now totally out of warranty and are not covered.
  • Call us to explain the problem, making sure you have both the model number and the serial number on hand. More often than not, we can resolve the matter over the phone.
5 Year Pro-Rated Warranty
For the first 2 years Warranty is unlimited.
  • During that period, your Distributor (in the USA, our Service Department) will repair or replace free of charge, at their discretion, any product that is proved to be faulty.
  • The Warranty period is taken from the date the goods leave our factory, although we will accept a later date if the Distributor can confirm date of purchase.
For the following 3 years Warranty is pro-rated.
  • During that period, your Distributor will replace with a new product at a discounted price.
  • These prices are set by each Distributor.
  • The Warranty period is taken from the date the goods leave our factory, although we will accept a later date if the Distributor can confirm date of purchase.
Conditions
  • We must receive back either an individual Transmitter or both Transmitter and Receiver, at your cost.
  • We will not accept individual Receivers. Always send both transmitter and receiver unless otherwise requested.
  • Discounted products will carry a further 2-year unlimited warranty. After 5 years Lodar cannot be repaired and will be scrapped.
  • Lodar 8000 Series are now totally out of warranty and are not covered.
  • Call us to explain the problem, making sure you have both the model number and the serial number on hand. More often than not, we can resolve the matter over the phone.
