Name: 6 Function Lodar Standard Wireless System | 9 Series FET | Keypad
Brand: Lodar LTD
SKU: 92106K-8
Price: 1300.00 USD
Availability: InStock
Rating: 5.0 (3 reviews)

The 6 Function Standard Wireless Control System from Lodar LTD, part of the 92 Series with a FET Keypad Receiver, features a transparent case that reveals its intricate circuit board and various buttons. This design enhances remote operation by showcasing the detailed electronic components, making it ideal for wireless control setups.

6 Function Lodar Standard Wireless System | 9 Series FET | Keypad

$1,300.00

1/2

6 Function Lodar Standard Wireless System | 9 Series FET | Keypad

92106K-8

3 reviews

$1,300.00

Choose Your Inserts

1 Choose Your Labels *

Quick Select Choose a preset configuration or customize below

Your Configuration Click on a zone to select an icon

F1 Click to select

F2 Click to select

F3 Click to select

F4 Click to select

F5 Click to select

F6 Click to select

Out of Stock

Complete plug-and-play wireless control system - includes the Standard handheld transmitter and the FET receiver, coded together at the factory and ready to wire to your equipment. Operates 6 functions on the Lodar 9 Series.

The 6 Function Lodar Standard Wireless System (92106K-8) gives you 6-function wireless control with a 150 ft (45 m) range on the 418 MHz band. Dc fet output switching, 10 A per output, 12/24V DC. It includes a master output - an additional output that energizes whenever any function is operated, for equipment that has to run alongside the controls (a hydraulic power unit during a lift, or a beacon while winching).

What does the keypad receiver add?

The keypad receiver lets you operate the 6 functions directly at the receiver with a built-in keypad, as a backup to the wireless handset. Confirm your power supply: this system runs on 12/24V DC. The FET receiver switches up to 10 A per output. Choose it when your functions draw more than the 5 A a relay receiver handles.

6 functions of wireless control
Standard transmitter - IP 54 rated
FET receiver - DC output switching, 10 A per output, 12/24V DC, wide band, IP 65 rated
12/24V DC operating voltage
150 ft (45 m) operating range, 418 MHz band
Keypad receiver - operate functions at the receiver as a wired backup
Master output - fires on every function for run-along equipment
Lodar SKU 92106K-8

Lodar 9 Series parts carry a trailing match code. This system ships as the -8 (the most common). If you are adding to or replacing parts in an existing Lodar system coded anything other than -8, contact us so the units pair correctly.

Want a different form of the same 6-function Lodar system? Compare the 6 Function Lodar Stainless IP Wireless System or 6 Function Lodar Standard Wireless Air System. Replacement handsets and receivers are sold separately.

Lodar 5 Year Pro-rated Warranty

Warranty is pro-rated and guarantees that product will be free of defect and faults from the manufacturer. See Lodar terms and conditions for more details.

92106 Series Options:

The 6 Function Standard Wireless Control System by Lodar LTD (92 Series) features two electronic control devices: a handheld remote with buttons, ideal for remote operation, and a clear-cased circuit board.

Standard Receiver 92106-8

-($114.00)

Keypad Receiver 92106K-8

6 Function Lodar Standard Transmitter | 9 SeriesSKU: 92106TX-8

$360.00

6 Function Replacement Keypad Receiver | 9 SeriesSKU: 9206RXK

$942.00

6 Function Lodar IP Transmitter | 9 SeriesSKU: 92206TX-8

$458.00

6 Function Lodar Standard Wireless System | 9 Series FET | Keypad

92106K - 6 Function + Keypad with Standard Transmitter Spec Sheet 92-93 Series - Wiring Instructions for 6 Function Receivers Wiring Diagram 92-93 Series - Instructions Standard Transmitter Coding Instructions

92-93 Series - Instructions Standard Transmitter Coding

5 Year Pro-Rated Warranty

For the first 2 years Warranty is unlimited.

During that period, your Distributor (in the USA, our Service Department) will repair or replace free of charge, at their discretion, any product that is proved to be faulty.
The Warranty period is taken from the date the goods leave our factory, although we will accept a later date if the Distributor can confirm date of purchase.

For the following 3 years Warranty is pro-rated.

During that period, your Distributor will replace with a new product at a discounted price.
These prices are set by each Distributor.
The Warranty period is taken from the date the goods leave our factory, although we will accept a later date if the Distributor can confirm date of purchase.

Conditions

We must receive back either an individual Transmitter or both Transmitter and Receiver, at your cost.
We will not accept individual Receivers. Always send both transmitter and receiver unless otherwise requested.
Discounted products will carry a further 2-year unlimited warranty. After 5 years Lodar cannot be repaired and will be scrapped.
Lodar 8000 Series are now totally out of warranty and are not covered.
Call us to explain the problem, making sure you have both the model number and the serial number on hand. More often than not, we can resolve the matter over the phone.
