The Lodar Service 6 Function IP Wireless Actuator Control System (92 Series, FET Air Receiver) includes four linear actuators, a handheld remote, and a wired control unit with exposed circuit board for wireless valve control.

6 Function Lodar IP Wireless Air System | 9 Series FET

$2,274.00
Skip to product information
The Lodar Service 6 Function IP Wireless Actuator Control System (92 Series, FET Air Receiver) includes four linear actuators, a handheld remote, and a wired control unit with exposed circuit board for wireless valve control.
1/2
  • The Lodar Service 6 Function IP Wireless Actuator Control System (92 Series, FET Air Receiver) includes four linear actuators, a handheld remote, and a wired control unit with exposed circuit board for wireless valve control.
  • Pairing the 92 Series Lodar Remote & Transmitter
  • The Lodar Service 6 Function IP Wireless Actuator Control System (92 Series, FET Air Receiver) includes four linear actuators, a handheld remote, and a wired control unit with exposed circuit board for wireless valve control.
  • Pairing the 92 Series Lodar Remote & Transmitter
6 Function Lodar IP Wireless Air System | 9 Series FET

6 Function Lodar IP Wireless Air System | 9 Series FET

92256-8
$2,274.00

Choose Your Inserts

1
Quick Select Choose a preset configuration or customize below
Your Configuration Click on a zone to select an icon
Configuration template
F1 Click to select
F2 Click to select
F3 Click to select
F4 Click to select
F5 Click to select
F6 Click to select
In Stock

Complete wireless air actuator control system - includes the IP handheld transmitter and a receiver with the pneumatic solenoid valves built into the box, coded together and ready to wire to your equipment. Operates 6 functions on the Lodar 9 Series.

The 6 Function Lodar IP Wireless Air System (92256-8) gives you 6-function wireless control with a 150 ft (45 m) range on the 433 MHz band. Compressed air is plumbed into the receiver box; the solenoid valves inside switch it to the output ports to drive your air cylinders directly - there is no separate external valve bank. Actuators are included. It includes a master output - an additional output that energizes whenever any function is operated, for equipment that has to run alongside the controls (a hydraulic power unit during a lift, or a beacon while winching).

Check your valve linkage before ordering. The actuators bolt onto the solid control rods your valve levers connect to, so you need clearance to mount them. A system with actuators included works only with solid "bang-bang" valve rods - not with valves operated by flexible cables or cords. If your valves are cable-operated, contact us.

Air supply. The air cylinders run on 21-120 psi (135 psi maximum); 80-100 psi is the ideal operating range. Plumb the system into a regulated air supply in that range.

How do I know this system fits my equipment?

Match the function count to the number of outputs you need to operate - 6 here - and confirm your power supply: this system runs on 12/24V DC. The FET receiver switches up to 10 A per output. Choose it when your functions draw more than the 5 A a relay receiver handles. The transmitter and receiver ship coded to each other, so the system works out of the box.

  • 6 functions of wireless control
  • 6 functions = 3 double-acting valves, two directions each
  • IP (Industrial Pro) transmitter - IP 65 rated
  • Air receiver - pneumatic solenoid valves built in, IP 65 rated
  • Air actuators included
  • 12/24V DC operating voltage
  • 150 ft (45 m) operating range, 433 MHz band
  • Master output - fires on every function for run-along equipment
  • Lodar SKU 92256-8

Lodar 9 Series parts carry a trailing match code. This system ships as the -8 (the most common). If you are adding to or replacing parts in an existing Lodar system coded anything other than -8, contact us so the units pair correctly.

Want a different form of the same 6-function Lodar system? Compare the 6 Function Lodar Standard Wireless Air System or 6 Function Lodar Standard Wireless Electric Actuator System. Replacement handsets and receivers are sold separately.

Common uses: Tow and recovery trucks, ag machinery, and industrial hydraulics where extended range is needed.
Lodar 5 Year Pro-rated Warranty icon

Lodar 5 Year Pro-rated Warranty

Warranty is pro-rated and guarantees that product will be free of defect and faults from the manufacturer. See Lodar terms and conditions for more details.
